RTMP is a protocol designed for flash. Unfortunately it can only be played by a flash player, or desktop clients such as VLC media player. With the move from flash to HTML 5 players, it is impossible to get an RTMP stream running.
I have been able to overcome this hurdle by creating a server which acts as an RTMP server, then converts the stream over to MP4 and serves it via HTTP. This is just a proof of concept, showing that it is possible to do. I plan on completing this project and putting it on github, however I just don't have the time for it right now, so here is a proof-of-concept which can be modified to suite your needs.
Before you can run this you will need to be in the directory containing server.js
(this is what I named the file).
## Before you can run the server
$ npm install http rtmpdump rtmp-server
$ sudo apt-get install rtmpdump
## server.js
#!/usr/bin/node
const RtmpServer = require('rtmp-server');
const rtmpServer = new RtmpServer();
rtmpServer.on('error', err => {
throw err;
});
rtmpServer.on('client', client => {
client.on('connect', () => {
console.log('connect', client.app);
});
client.on('play', ({ streamName }) => {
console.log('PLAY', streamName);
});
client.on('publish', ({ streamName }) => {
console.log('PUBLISH', streamName);
});
client.on('stop', () => {
console.log('client disconnected');
});
});
rtmpServer.listen(1935);
var rtmpdump = require('rtmpdump');
var fs = require('fs');
var options = {
rtmp: 'rtmp://127.0.0.1/live',
playpath: 'poc',
v: null // parameter-less command line switches must have null as a value
};
var stream = rtmpdump.createStream(options);
stream.on('connected', function(info) {
// info provides various details about the stream
// duration, resolution, codecs, ...
console.log(info);
});
stream.on('progress', function(kbytes, elapsed, percent) {
console.log('%s kbytes read, %s secs elapsed, %s%%', kbytes, elapsed, percent);
});
stream.on('error', function(err) {
// as usual, unhandled error events will throw
console.log(err);
process.exit(1);
});
stream.on('exit', function(err) {
console.log(err);
});
var http = require('http');
//create a server object:
http.createServer(function (req, res) {
stream.pipe(res); //write a response to the client
}).listen(8080); //the server object listens on port 8080
Once setup you can run and start streaming to the server. To stream fire up OBS and put the following information in:
* **Host:** rtmp://127.0.0.1/live
* **Stream Key:** poc
Now point VLC or your HTML5 player of choice to http://127.0.0.1:8080/
and the stream will start to play.
